EV Power Westart NCM 3.7V CellsEV Power represents Shenzhen Westart Lithium NCM cell manufacturer.
30% lighter and 30% more energy dense than LiFePO4. Perfect for traction applications. Fast charge and discharge, Deep Cycle. 100% recyclable and non-toxic.
- Voltage: 3.7V nominal, 4.2V max, 3.0V min
- Long Cycle life >2000 cycles.
- high discharge rate 2C cont./ 5C burst.
- Consistently low internal resistance. (=longer life)
- Safe NCM chemistry, proven performance in EVs.
- Higher energy density This means more Ah in a smaller lighter package.
An appropriate charger and battery management system is required for cell balancing and protection from overcharge and over-discharge.
| EV POWER | CELL | CHART | Bolt | Bolt | EV Power | ||
| Model | Capacity | Weight | Dimensions WxLxH | Size | Spacing | BMS module | |
| NCM25AH | 25Ah | 0.5kg | 9 x 133 x 230mm | TAB | 67.5mm | Batmon-12S | |
| NCM90AH | 90Ah | 1.75kg | 29 x 135 x 235mm | M8 | 67.5mm | CBM-NCM | |
| NCM120AH | 120Ah | 2.5kg | 38 x 135 x 235mm | M8 | 67.5mm | CBM-NCM |
Westart High Power NCM 25Ah cell specification
Westart High Power NCM 30Ah cell specificationV1.2
Westart NCM 90Ah module specification Westart NCM 120Ah module specification
Westart NCM 120Ah module specification
Most times only a few cells are kept in stock. NCM Cells from Westart are subject to continuous improvement so specifications change (improve) regularly. For larger orders we can order ex-factory at excellent rates. Note that we are the Australian agent. If you are based in Australia please work through us. We take pride in being honest and up-front with information.
EV Power NCMPak (12S) 44V 100AH, 29kg, 4.44kWhrs = 153 Whr/kg. 495 x 142 x 280(h)mm including BMS electronics = 225 Whr/litre
